| GE SFP Slots |
4 |
| GE RJ45 Interfaces |
14 |
| GE RJ45 WAN Interfaces |
2 |
| GE RJ45 Management/HA Ports |
2 |
| USB Ports |
2 |
| RJ45 Console Port |
1 |
| Local Storage |
– |
| Included Transceivers |
0 |
| System Performance and Capacity |
| Firewall Throughput (1518 / 512 / 64 byte, UDP) |
20 / 20 / 9 Gbps |
| Firewall Latency (64 byte, UDP) |
3 μs |
| Firewall Throughput (Packet per Second) |
13.5 Mpps |
| Concurrent Sessions (TCP) |
2 Million |
| New Sessions/Second (TCP) |
135,000 |
| Firewall Policies |
10,000 |
| IPsec VPN Throughput (512 byte) |
7.2 Gbps |
| Client-to-Gateway IPsec VPN Tunnels |
10,000 |
| SSL-VPN Throughput |
900 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
5,00 |
| SSL Inspection Throughput (IPS, avg. HTTPS) |
820 Mbps |
| SSL Inspection CPS (IPS, avg. HTTPS) |
1000 |
| Application Control Throughput (HTTP 64K) |
3.5 Gbps |
| CAPWAP Throughput (1444 byte, UDP) |
1.5 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
| Maximum Number of FortiSwitches Supported |
24 |
| Maximum Number of FortiAPs (Total / Tunnel) |
128 / 64 |
| Maximum Number of FortiTokens |
5,000 |
| Maximum Number of Registered FortiClients |
600 |
| High Availability Configurations |
Active-Active, Active-Passive, Clustering |
| System Performance — Enterprise Traffic Mix |
| IPS Throughput |
2.2 Gbps |
| NGFW Throughput |
1.8 Gbps |
| Threat Protection Throughput |
1.2 Gbps |
| Dimensions and Power |
| Height x Width x Length |
1.75 x 17.0 x 11.9 inches
44.45 x 432 x 301 mm
|
| Form Factor |
1 RU |
| AC Power Supply |
100–240V AC, 60–50 Hz |
| Power Consumption (Average / Maximum) |
70.98 / 109.9 W |
| Heat Dissipation |
374.9 BTU/h |
| Operating Environment and Certifications |
| Operating Temperature |
32–104°F (0–40°C) |
| Storage Temperature |
-31–158°F (-35–70°C) |
| Humidity |
10–90% non-condensing |
| Noise Level |
31.1 dBA |
| Operating Altitude |
Up to 7,400 ft (2,250 m) |
| Compliance |
FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB |
| Certifications |
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6 |
