Tín Bảo Lan (TBL)
  • - Recommended: for 301-500 User Network
  • -Threat Protection Throughput: 5 Gbps
  • -Site-to-Site VPN Tunnels: 2,000
  • -Concurrent Sessions: 4,000,000
  • -1 Year Services: 24x7 FortiCare Contract & FortiGuard Unified Threat Protection (UTP)


Giá Liên Hệ






  • Thông tin chi tiết
  • Đánh giá
Mã sản phẩm FG-400E-BDL-950-12
Interfaces and Modules
GE RJ45 Interfaces  16
GE SFP Slots  16
GE RJ45 Management Ports  2
USB Ports  2
RJ45 Console Port  1
Local Storage NIL
Included Transceivers  2x SFP (SX 1 GE)
System Performance — Enterprise Traffic Mix
IPS Throughput 2 7.8 Gbps
NGFW Throughput 2, 4 6 Gbps
Threat Protection Throughput 2, 5 5 Gbps
System Performance and Capacity
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) 32 / 32 / 24 Gbps
IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP) 32 / 32 / 24 Gbps
Firewall Latency (64 byte, UDP)  3 μs
Firewall Throughput (Packet per Second)  36 Mpps
Concurrent Sessions (TCP)  4 Million
New Sessions/Second (TCP)  450,000
Firewall Policies  10,000
IPsec VPN Throughput (512 byte) 1 20 Gbps
Gateway-to-Gateway IPsec VPN Tunnels  2,000
Client-to-Gateway IPsec VPN Tunnels  50,000
SSL-VPN Throughput  4.5 Gbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) 5000
SSL Inspection Throughput (IPS, HTTPS) 3 4.8 Gbps
SSL Inspection CPS (IPS, avg. HTTPS)3 4,000
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3 300,000
Application Control Throughput (HTTP 64K) 2 12 Gbps
CAPWAP Throughput (1444 byte, UDP) 14.8 Gbps
Virtual Domains (Default / Maximum)  10 / 10
Maximum Number of Switches Supported  48
Maximum Number of FortiAPs (Total / Tunnel) 512 / 256
Maximum Number of FortiTokens  5,000
Maximum Number of Registered Endpoints  600
High Availability Configurations  Active-Active, Active-Passive, Clustering
Dimensions and Power
Height x Width x Length (inches)  1.75 x 17.0 x 15.0
Height x Width x Length (mm)  44.45 x 432 x 380
Weight  16.4 lbs (7.4 kg)
Form Factor  1 RU
Power Consumption (Average / Maximum)  109 W / 214 W
Power Source  100–240V 60–50Hz
Current (Maximum)  6A
Heat Dissipation  730 BTU/h
Redundant Power Supplies (Hot Swappable)  optional
Operating Environment and Certifications
Operating Temperature  32–104°F (0–40°C)
Storage Temperature  -31–158°F (-35–70°C)
Humidity  10–90% non-condensing
Noise Level  48 dBA
Operating Altitude  Up to 7,400 ft (2,250 m)
Compliance  FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB
Certifications  ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6

Tùy chọn Module quang SFP cho Firewall FortiGate 400E

1 GE SFP LX transceiver module FN TRAN LX 1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots.
1 GE SFP RJ45 transceiver module FN TRAN GC  1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+slots.
1 GE SFP SX transceiver module FN TRAN SX 1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots.

Tùy chọn Power nguồn cho Firewall FortiGate 400E

Optional Power Supply SP-FG300E-PS AC power supply for FG-300/301E, FG-400/401E, FG-500/501E, FG-600/601E, FAZ-200F/300F/800F and FMG-200F/300F
