| Ports |
4 RJ-45 autosensing 10/100/1000 PoE+ ports
4 RJ-45 autosensing 10/100/1000 ports |
| Processor |
ARM Cortex-A9 @ 400 MHz |
| RAM |
256 MB SDRAM |
| Flash |
64 MB |
| Packet buffer size |
1.5 MB |
| Latency |
100 Mb Latency: < 7 μs
1000 Mb Latency: < 2.3 μs |
| Jumbo frame support |
9216 bytes |
| Throughput |
11.9 Mpps |
| Switching capacity |
16 Gbps |
| MTBF |
112.4 years |
| MAC address size |
8K entries |
| Layer 2 Switching |
VLAN, Spanning Tree, BPDU filtering |
| Layer 3 Services |
ARP, DHCP Relay |
| Layer 3 Routing |
Static IPv4 routing, Link aggregation, Convergence, |
| Voltage |
100 – 240 VAC |
| PoE Power |
65 W PoE+ |
| Maximum power rating |
72.9W |
| Operating temperature |
0°C to 40°C |
| Operating relative humidity |
15% to 95%, noncondensing |
| Dimensions |
25.4 x 15.95 x 4.39 cm (1U height) |
| Weight |
0.91kg |
